SolarWedge® XD commercial tilted racking system uses the ProSolar® 3" XD RoofTrac® Rail to support systems spanning up to 8' on center, while ensuring seismic safety by structurally attaching to roof rafters

Details:

  • Self-bonding, patented system designed for flat roof projects
  • Available in 5, 10, and 15-degree tilt angles
  • Features UL2703 listed RoofTrac® Rail Clamping Technology and ChemLink™ E-Curb™  easy, low-cost sealant system.
  • Each system engineered and load tested to 30 lb/sq. ft. (equivalent of 110 mph winds per 2013 CBC / 2012 IBC / ASCE 7-10)
  • Spans 8 foot on center max when used with 3" tall RoofTrac® XD rail
  • Class A Fire Rated for Type 1 and 2 Modules -Requires 4.5" Commercial FastJack® E-Series Extension (as shown)

SolarWedge Display


* Integrated with Commercial FastJack® E-Series to maintain required 14" clearance.

Accessories:

 Brochure | Installation Guide



For Sloped Roofs See: RoofTrac®

Components:

SolarWedge®
